Heat shrinking fabric wrap tape roll is made from polyester fiber as raw material and woven by advanced high-speed looms.
Description
Heat shrinking fabric wrap tape roll is made from polyester fiber as raw material and woven by advanced high-speed looms.
Specification:
MOQ: 5,000 Rolls (250rolls/carton)
Thickness: 0.10-0.30mm
Width: 10-100mm
Color: white
Technical Parameter
Property | Unit | Index value | ||
Nominal thickness | mm | 0.23 | 0.26(oblique) | 0.29 |
Width tolerance | mm | ±1 | ||
Shrinkage | % | ≥30 | ||
Tensile Strength | N/10mm | ≥200 | ||
Stains | - | No rust | ||
Broken head | - | Two segments allowed each roll, each segment is no less than 3m in length. | ||
Hole | - | There should be no warp or more than 3 holes | ||
Storage period | Month | 12 months | ||
Characters
Heat-resistance: B Class (130℃)
Good impregnation effect
High shrinkage rate (40-50%)
Application
Heat shrinking fabric wrap is widely used as banding material for motor and transformer coils.
