It is applicable to all kinds of transformer winding iron core winding equipment and different core sections (round, composite, polygon, etc.).
Product Description
Features:
1. It is applicable to all kinds of transformer winding iron core winding equipment and different core sections (round, composite, polygon, etc.).
2. Full-featured: Simultaneously symmetrical winding (planar single-phase, planar three-phase coil core winding) and asymmetric winding (three-dimensional triangular core winding), and two different winding methods are easy to convert.
3. An automatic centering device is used to ensure that the desired cross-sectional shape is achieved during winding.
4. When winding, the silicon steel strip is stretched by roller pressing and sliding friction, and the tension can be adjusted to ensure tight winding.
Technical Parameter:
Maximum diameter of the iron core: | Φ250mm(planar roll) Φ400mm(three-dimensional roll) |
Maximum turning radius: | R650mm(pressurized wheel) R800mm(no pressure wheel) |
Winding speed | 0-36r/min |
Speed control | Stepless frequency speed adjustment |
Motor power | 5.5-7.5KW |
